Midea MWSC340A-FB3 - Page 23

Flooded type water cooled screw chiller (PCB Control)
22
Flooded type (Condenser)
0
10
20
30
40
50
60
70
80
90
100
80 130 180 230 280 330 380
Water pressure drop(kPa)
Water flow (m3/h)
Water pressure drop curve(evaporator)
MWSC1080A-FB3
MWSC1200A-FB3
MWSC1385A-FB3
MWSC1620A-FB3
MWSC1780A-FB3
0
10
20
30
40
50
60
70
80
90
100
20 70 120 170 220
Water pressure drop(kPa)
Water flow (m3/h)
Water pressure drop curve(condenser)
MWSC340A-FB3
MWSC440A-FB3
MWSC540A-FB3
MWSC690A-FB3
MWSC805A-FB3
MWSC890A-FB3
0
20
40
60
80
100
120
100 200 300 400
Water pressure drop(kPa)
Water flow (m3/h)
Water pressure drop curve(condenser)
MWSC1080A-FB3
MWSC1200A-FB3
MWSC1385A-FB3
MWSC1620A-FB3
MWSC1780A-FB3
