Flooded type water cooled screw chiller (PCB Control)
78
Foundation Bolt Installation Dimension Table
3) Vibration isolators
Put the absorbers under unit saddles before final positioned the unit. The quantity of absorber used
for each unit is always decided by the elasticity or durometer value of the absorber. Below please
refer to the typical isolation pad and vibration isolator for selection.
Typical isolation pad Typical vibration Isolator
≥
Expected load bearing value listed below:
Model
Isolation pad
Vibration Isolator
Running
weight(kg)
Minimum load
bearing (kg/EA)
Minimum
Quantity
Minimum load
bearing (kg/EA)
Quantity
MWSC340A-FB3
900
4
900
4
2700
MWSC440A-FB3
1000
4
1000
4
2820
MWSC540A-FB3
1200
4
1200
4
3220
MWSC690A-FB3
1400
4
1400
4
3870
MWSC805A-FB3
1800
4
1800
4
4420
MWSC890A-FB3
1800
4
1800
4
4550
MWSC1080A-FB3
2000
4
2000
4
7250
MWSC1200A-FB3
2200
4
2200
4
7490
MWSC1385A-FB3
2200
4
2200
4
7820
MWSC1620A-FB3
2200
4
2200
4
9200
MWSC1780A-FB3
2200
4
2200
4
9350
Note:
Model
Dimension
MWSC***A-FB3
340
440
540
690
805
890
1080
1200
1385
1620
1780
D(mm)
2850
2850
2850
2850
2850
2850
3850
3850
3850
3850
3850
E(mm)
1100
1100
1100
1300
1300
1300
1400
1400
1400
1500
1500
