1. Take a unified power line component, insert
the lead wire into the bottom cover hole to the
power line tap card into the hole position, and
rotate the tap card 90 degrees with a flat
clamp;
2. Take a stilt-plate switch and insert the 187
terminal of the thermostat through the chassis
hole into the "I" end, and the power cord fire
(brown line) is connected to the "O" end;
3. Press the rocker switch limit bar to the
bottom of the bottom cover slot and place the
power cord in the bottom cover limit bar.
1. 取一配重块将宽边孔位对应前壳限位柱放
置好。取一后壳检查无划花、变形、缺料等
不良，对准底部、前壳左右两侧卡扣按压到
位，完全吻合；
2. 将底盖对应前后壳套入，使用双手压住底
盖轻推使底部扣位完成卡到位。分别取 2 颗
ST3.5*13 螺钉将底盖紧固。
1. Take a weight distribution block and place
the wide edge hole position corresponding to
the front shell limit column. Take a back shell
to check no scratches, deformation, lack of
materials, etc.
2. Insert the bottom cover into the front and
rear shell, and press the bottom cover with
