1)松开风机组件与前壳的螺钉，取下蜗壳扣位
中的线束，取出风机组件。
1) Loosen the screws that fix the Fan component
and the front cover, Remove the wires from the
volute buckle, then remove the Fan component.
2)松开 PTC 组件与上下转轴之间的螺钉，上下
转轴与风道之间的螺钉，风轮与电机转轴之间
的螺钉，电机与风道之间的螺钉，取下 PTC 组
件、上下转轴、风轮、电机与蜗壳。
2）Loosen the screws that fix the PTC assembly
and up/down rotation axis, the up/down rotation
axis and the wind channel, the wheel and the
motor, the motor and the wind channel, the
volute tongue plate and the wind channel. Then
remove them.
