Page 1
1.2 System Parts
FAN ASSEMBLY
PTR VALVE
TOP COVER
EVAPORATOR FILTER
ANODE ROD
UPPER REAR COVER
UPPER FRONT COVER
HOT WATER OUTLET
COLD WATER INLET
DRAIN PORT
ELECTRIC ELEMENT
FRONT FASCIA
TEMPERATURE SENSOR
ELECTRONIC CONTROL BOX
POWER CONNECT BOX & COVER
COMPRESSOR
DISPLAY
ANODE ROD COVER
ATCO
TCO
ELECTRICAL ELEMENT COVER
NOTE
All pictures in this manual are for explanation purpose only.
They may different from the actual unit.
978 (PTR CONNECTION)
978 (HOT OUTLET)
685 (COLD INLET)
1580 (HEIGHT)
568 (WIDTH)
1215 (ELECTRICAL ENTRY)
MIN 700
(SUPPORT BASE)
MIN 700
(SUPPORT BASE)
PRODUCT
INFORMATION & SCHEMATICS
1
1.1 System Schematics (Dimensions in millimetres)
