Connectingthedrainhoses


Insertthedrainhoseintoadrainpipewithaminimumdiameterof4cm
orletitrunintothesink,takingcarenottokinkorcrushit.Theheightof
thedrainhosemustbelessthan1,000mm.Toavoidbackflowinthe
hose,thefreeendofthehosemustnotbeimmersedinwater.

FixthedrainhosesecurelyinpositionAorB.



















Drainingexcesswaterfromhoses
If the sink is 1,000 mm higher than the floor, the excess water in the
hoses cannot be drained directly into the sink. In this case, excess
water from the hoses must be drained into a bowl or suitable vessel
locatedoutsideandlowerthanthesink.

Watersupply
Connectthewaterdrainhose.Thedrainhosemustbecorrectlyinstalledto
preventwaterleaks.Ensurethatthewaterhoseisnotkinkedorcrushed.
worktop

backofdishwasher

A

B

watersupply

Ø40mm

drainpipe

maincable

drainhose

max.1,000mm

