V8 VRF Indoor Units
16
Midea
V8
Series VRF Indoor Units
13
CN190
Drainage pump port
14
CN30
Display panel connection
15
CN8
EEV drive port
Using other ports’ GND
21
CN25
Program burning port(indoor unit)
23
CN99
After-sale Kit communication port
3.3V
GND
12V
GND
12V
GND-L
12V
GND
12V
