Brush-roll and Cover cleaning
17
Attention
1. 2.
3. 4.
It is recommended that after each use, the roller brush and cover should be
cleaned and dried in time;
If residual stains are found on the suction surface of the floor brush, wipe it
with a wet cloth. Do not rinse it with water.
1.
2.
Press the latch as shown, and
remove the cover and the roller
brush;
Remove the cover and the roller
brush, open the rotating blade of
the cleaning brush, and remove
the hair and other entanglements
on the roller brush;
Remove the small roller brush
and large roller brush in the
direction shown in the figure
and rinse the roller brushes and
cover with clean water;
After cleaning, install the small
and large roller brushes in turn
according to the direction shown
in the figure. The installation is
successful when you hear a click
sound.
Small
brush-roll
Large
brush-roll
Handle
