midiplus PianoEngine - Panel Description

MIDIPLUS Co, Ltd.
5
2.11 To protect the battery and extend the battery life, please do not use it for a
long time in a low battery state. When it is lower than 2%, the power will be
automatically turned off.
2.12 The USB HOST port of PianoEngine provides standard USB 5V 500mAh current
output, and can also be used as an emergency mobile phone charger to
charge your mobile phone.
2.13 You can charge your PianoEngine with Micro-USB to any device with a USB
port (computer, power bank, etc.).
2.14 Port: 3.5mm TS Audio input port, 3.5mm TS headphone output port, MIDI IN/
OUT port, USB HOST port, Micro-USB charging & power supply port.
Ch3. Panel Description
USB/MIDI Sign Light
LCD Monitor
Preset A, B & C
Set
Shift
Volume
Drum
Sound
Save
Channel
Knob
