USER PANEL
Pitch and Modulation Wheel Plus/Minus Keys
Data entry Slider Advanced Functions and Ten Keys
Display Controller Knobs
Basic Functions
BACK PANEL CONNECTIONS
1 = Footpedal 2 = Soundexpander 3 = Computer 4 = Power supply
5
