Controls & Indicators
7
1. Antenna Connector
2. CH Up/Down buttons
3. Backlight Button
4. Last Channel Recall
5. “Push To Talk”
6. Dual Function Button
7.
Memory Channels/H/L Power
8. Squelch Control
9. On/Off Volume Knob
Note: See pages 9-10
for details.
1
2
3
5
6
4
8 9
