OPERATION CONTROLS – MIC
1 LCD Display
2 Speaker Mic Jack
3 Menu Button
4 Call Button
5 Key Pad Lock Button
6 Microphone
7 Volume
/Me
nu Navigation Buttons
8 WX Button
9 Monitor Button
10 Scan Button
11 TX/RX Indicator
12 PTT Button
13 Channel Down Button
14 Power Button
15 Channel Up Button
FRONT PANEL CONNECTIONS
1 Microphone Jack
2 USB-C Port
BACK PANNEL CONNECTIONS
1 Antenna Jack
2 External Speaker Jack
3 Intercom Jack
LCD DISPLAY
1 Channel Icon
2 Receive Indicator
3 Repeater Channel Indicator
4 Transmit Indicator
5 CTCSS Privacy Tone
6 Power Level Icons
7 DCS Privacy Tone
8 Scan Indicator
9 Key Lock
10
11
Monitor Mode
Signal Strength
