Chapter 1: Before You Begin
Chapter 2: Specicaons
Disposal
Do not dispose of this device with normal
domestic waste!
To comply with the European Directive 2002/96/EC on Waste
Electrical and Electronic Equipment and its implementation
as national law, electrical equipment that has reached the
end of its life must be collected separately and returned
to an approved recycling facility Any device that you no
longer require must be returned to our agent, or nd out
about the approved collection and recycling facilities in your
area. Ignoring this European Directive may have potentially
adverse aects on the environment and your health! Please
be aware that in other parts of the world local legislation
should be followed.
Conventions used in this manual
To help you learn how to use your charger the manual uses
these symbols and typographical conventions:
Convention Description
!
The safety symbol indicates instructions for avoiding hazardous conditions and personal injury.
The safety symbol with the words CAUTION, WARNING, or DANGER indicates instructions for
avoiding hazardous conditions and personal injury.
CAUTION
The word CAUTION indicates instructions for avoiding equipment damage.
The wrench symbol indicates procedural notes and helpful information.
UP ARROW
The text for keypad buttons are in Bold capital letters.
CAPITAL LETTERS The text for screen options are in regular capital letters.
BACK ARROW
The text for soft keys are in Bold capital letters.
Chapter 1: Before You Begin
General
Lead-acid batteries GEL, AGM/SPIRAL, Flooded,
Power supply
Number of cells 6
Rated capacity 20 to 250Ah
Note: A 24 V operation consists of two 12 V (6cell) batteries
connected in series.
Input Ratings
230 V AC (16A) 50 / 60Hz
(Tolerance: 190 - 265 V AC 50 / 60Hz)
Output Ratings
Charger DC Voltage Amps Watts
PRO 50 12 V 50 A single channel
2x 25 A dual channel
660
Chapter 2: Specications
