Please refer to the installation
diagram supplied with the machine.
,
Furniture and fittings installed
near the machine must be of a
commercial standard, able to
withstand the effects of steam and
condensed water.
Installation options
–
Free-standing
–
Undercounter
The machine should be positioned
under a continuous worktop or sink
drainer.
The opening must be at least 23 5/8"
(60 cm) wide, 23 5/8" (60 cm) deep and
34 1/4" (82 cm) high.
If necessary, the machine lid can be
removed as follows:
^
Open the door.
^ Remove the fixing screws on both
sides using a Phillips screwdriver.
^ Pull the machine lid approx. ¼"
(5 mm) forwards, lift and remove.
Installation
47
