Building-in several CombiSets
43
Calculating the worktop cut-out
The frames of the CombiSets overlap the worktop at the outside right and left by
8mm on each side.
 Add up the widths of the CombiSets and subtract 16mm from this figure.
Example:
288 mm + 288 mm + 380 mm = 956 mm - 16 mm = 940 mm
The CombiSets are 288mm, 380mm or 576mm wide depending on model (see
"Building-in dimensions").
Spacer bars
When building-in several CombiSets, an additional spacer bar must be fitted for
each additional CombiSet. The position for securing the spacer bar will depend on
the width of the CombiSet.

Miele CS 1018 G Specifications

General

Brand	Miele
Model	CS 1018 G
Category	Hob
Language	English
