Miele CVA 5060 Operating Instructions

Before using for the first time
The machine must be correctly installed and connected
(see "Electrical connection " and "Installation") and also
cleaned (see "Cleaning and care") before it is used for the
first time.
Remove any protective foil from the front of the machine.
Switching on
^
Touch the On/Off sensor s to switch on the machine.
When the machine is being switched on for the first few times
with the master switch, a welcome screen and some other
messages will appear briefly. The welcome screen will be
displayed each time the machine is switched on until 5 drinks
have been prepared.
Míele
Willkommen
When you use the machine for the very first time instead of
the time of day appearing after the welcome screen you will
be prompted to select a language.
^
Use the right or left arrow until the language you want to
select appears in the display.
^
Touch the OK sensor.
The language you have chosen is now set.
The request to set the clock format will then appear.
^
Use the arrows to select the clock format you want (12 h or
24 h) and then touch the OK sensor.
Using the coffee machine - first steps
17

Miele CVA 5060 Specifications

General

Type	Coffee/Espresso
Product type	Espresso machine
Capacity in cups	15 cups
Coffee input type	Coffee beans
Coffee maker type	Fully-auto
Appliance placement	Built-in
Water tank capacity	2.3 L
Coffee beans capacity	500 g
Adjustable coffee strength	Yes
Maximum operating pressure	15 bar
Cord length	3 m
Product color	Black, Stainless steel
Housing material	-
AC input voltage	220–240 V
AC input frequency	50 - 60 Hz

Weight and Dimensions

Depth	480 mm
Width	595 mm
Height	455.5 mm
Installation compartment depth	500 mm
Installation compartment width	560 mm
Installation compartment height	450 mm
