Installation
34
Secur
e the rangehood to the
brackets from below using two
screws on each side.
P
ull out the deflector plate and
remove the protective film between
the deflector plate and the casing.
Secur
e the rangehood to the floor of
the housing unit from below using 4
screws (6 screws are required for a
90 cm wide rangehood).
To avoid damaging the deflector
plate when it is pulled out, care
should be taken to screw the fixing
screws in straight and to ensure that
the screw heads are countersunk.
Secur
e the spacer strip to the back of
the appliance from behind using 4
plastic rivets as shown.
