Building-in dimensions
43
EVS with DGC6660 / DGC686x
a
Ventilation cut-out required when in-
stalled with a steam combination
oven
b
Building-in dimension including
mains supply cable plug connector
Mains connection cable
L=2200mm
*Glass front / **metal front
For the DGC 6865 cut-outs are re-
quired for the water inlet and drain
hoses (see DGC 6865 installation in-
structions).
EVS with DGD4635 / DGD6xx5
a
Filler panel AB 45-7 (optional ac-
cessory)
b
Building-in dimension including
mains supply cable plug connector
Mains connection cable
L=2200mm
*Glass front / **metal front
For the steam oven with pressure, cut-
outs are required for the water inlet
and drain hoses (see installation in-
structions for steam oven with pres-
sure).
