Attaching the appliance to the
installation niche
^ Open the appliance door.
^ Fasten the appliance on the left and
right hand sides with the 3 (supplied)
wood screws.
If there is a fairly large gap above the
appliance, cut a wooden beam to fit
exactly and place it in the gap.
Now connect the water supply to the
appliance (see "Plumbing").
Attaching the toe-kick cover
The maximum height of the toe-kick
cover is 4" (102 mm) from the top of
the floor. Do not cover the ventilation
slits in the plinth. Risk of damage to
the appliance.
^
If required, cut the toe-kick cover to
the required length and height.
^
Attach the plinth to the appliance,
and put the included cover plates in
place.
Installing the appliance
69
