Miele F1471SF - Attaching the Frame and the Shelf

Attaching the frame and the
shelf
The word "TOP" is marked on the
rear of the frame at the top.
For
3
/
4
" (19 mm) thick custom doors:
^ Slide the cover frame onto the
Ice/Water Dispenser and press until it
is flush with the door front.
For 1
1
/
2
" / (38 mm) thick custom doors:
^
Fit the extension trim onto frame.
^
Fit the cover frame onto the Ice/Water
Dispenser and press it firmly into
position until it is flush with the door
surface.
Installing the appliance
73
