Technical Information
63
G 1xxx/G 2xxx
4.9
Comfort Door Closing Aid (CTSH) Removal (LaPerla II)
1.
Remove the top insulating mat.
2.
Open the door.
3.
Disconnect the plug connections.
4.
Release the snap clip.
5.
Pull the CTSH with adjustable door lock latch below the top door seal
through towards the back.
62
64
Table of Contents
Default Chapter
2
Table of Contents
2
Technical Information
12
Warning and Safety Instructions
12
General Information
12
Touch Current Measurement
12
Risk of Injury Due to Sharp Edges and Protruding Parts
13
Uninstalling the Dishwasher
13
Service Work - Casing
13
B Modification History
13
C Technical Data
14
Data Sheets
14
Inspira, Inspira II
14
Table C-1: US Data Sheet, Inspira/Inspira II Models
14
Diamante, Diamante Plus
15
Table C-2: US Data Sheet, Diamante/Diamante Plus Models
15
Optima, Optima II
16
Table C-3: US Data Sheet, Optima/Optima II Models
16
Excella, Excella II
17
Table C-4: US Data Sheet, Excella/Excella II Models
17
Laperla, Laperla II
18
Table C-5: US Data Sheet, Laperla/Laperla II Models
18
Advanta
19
Table C-6: US Data Sheet, Advanta Models
19
Door Springs
20
Summary
20
Standard Door Springs by Appliance Model
20
Table C-7: Door Springs Summary
20
Table C-8: Standard Door Springs by Model
20
Door Springs Supplied as Spare Parts
21
Electrical and Plumbing Connections
21
Electrical Information
21
Table C-9: Door Springs Supplied as Spare Parts
21
Hard-Wired Electrical Connection
22
Plumbing Connections
22
Intake Connection
22
Drain Connection
22
D Layout of Electrical Components
23
Control Panels
23
Novotronic
23
Touchtronic
23
Figure D-1: G 2020 Fascia Panel
23
Figure D-2: G 1202 Fascia Panel
23
Figure D-3: G 2120, G 214X, G 2150 Fascia Panel
24
Figure D-4: G 2143 Fascia Panel
24
Figure D-5: G 2420, G 2430 Fascia Panel
24
Figure D-6: G 2432 Fascia Panel
24
Incognito
25
Figure D-7: G 2630, G 2732 Fascia Panel
25
Figure D-8: G X18X, G 2170 Fascia Panel
25
Figure D-9: G 1262 Fascia Panel
25
Figure D-10: G X470 Fascia Panel
25
Figure D-11: G X472 Fascia Panel
25
Navitronic
26
Figure D-12: G 2670 Fascia Panel
26
Figure D-13: G 2872 Fascia Panel
26
Figure D-14: G 283X Fascia Panel
26
Appliance Overviews
27
Integrated Models, Salt Container in Sump
27
Figure D-15: Integrated Model with Salt Container in Sump
27
Fully Integrated Models, Salt Container in Sump
28
Figure D-16: Fully Integrated Model with Salt Container in Sump
28
Integrated Models, Salt Container in Door
29
Figure D-17: Integrated Model with Salt Container in Door
29
Fully Integrated Models, Salt Container in Door
30
Figure D-18: Fully Integrated Model with Salt Container in Door
30
Fully Integrated Models, no Salt Container (Slimline)
31
Figure D-19: Fully Integrated Model Without Salt Container
31
Component Layouts
32
G 2020 (Advanta with Novotronic)
32
Figure D-20: G 2020 Component Layout
32
G 1202, G 2120, G 214X, G 2150 (Optima Slimline, Inspira, Diamante with Touchtronic)
33
Figure D-21: G 1202, G 2120, G 214X, G 2150 Component Layout
33
G 2420, G 243X (Optima Full-Size with Touchtronic)
34
Figure D-22: G 2420, G 243X Component Layout
34
G 2630, G 2732 (Excella with Touchtronic)
35
Figure D-23: G 2630, G 2732 Component Layout
35
G 1262, G 2170, G X18X (Optima Slimline, Advanta, Diamante, Inspira with Incognito)
36
Figure D-24: G 1262, G 2170, G X18X Component Layout
36
G X47X (Optima Full-Size with Incognito)
37
Figure D-25: G X47X Component Layout
37
G 2670 (Excella with Incognito)
38
Figure D-26: G 2670 Component Layout (US Only)
38
G 2872 (Laperla II with Incognito)
39
Figure D-27: G 2872 Component Layout
39
G 2830 (Laperla with Navitronic)
40
Figure D-28: G 2830 Component Layout
40
G 2832 (Laperla II with Navitronic)
41
Figure D-29: G 2832 Component Layout
41
G 1Xxx/G 2Xxx
38
Data Tag
42
Model Numbering
42
Figure D-30: Data Tag Location
42
Figure D-31: Data Tag Information
42
Figure D-32: Model Numbering
42
Casing
43
Service
44
Side Panel Removal
44
Figure 010-1: Side Panel Removal
44
Drip Pan Removal
45
Hinge Removal
45
Figure 010-2: Drip Pan Removal
45
Figure 010-3: Opening the Hinge Bracket
46
Figure 010-4: Front Hinge Retaining Screw
46
Figure 010-5: Side Hinge Retaining Screw
47
Door
48
Function
49
Door Handle and Door Lock (Novotronic/Touchtronic/Navitronic)
49
Child Safety Lock
49
Figure 020-1: Door Handle Release
49
Figure 020-2: Child Safety Lock
49
Door Lock (Incognito)
50
Comfort Door Closing Aid (Laperla II)
50
Figure 020-3: Door Handle Release
50
Figure 020-4: Door Lock Latch
51
Figure 020-5: Door Lock Latch, Position 1
52
Figure 020-6: Door Lock Latch, Position 2
53
Figure 020-7: Door Lock Latch, Position 3
54
Figure 020-8: Door Lock Latch, Intermediate Opening Position
55
Figure 020-9: Door Lock Latch, Intermediate Closing Position
56
Combination Dispenser
57
Figure 020-10: Combination Dispenser
57
G 1Xxx/G 2Xxx
52
Fault Repair
58
Door Can't be Closed
58
Fault with Automatic Door Closing/Opening (Laperla II)
58
Service
59
Removing the Combination Dispenser
59
Cable Holder Removal
59
Locking Plate Adjustment
59
Figure 020-11: Combination Dispenser Removal
59
Bottom Door Seal Removal
60
Figure 020-12: Door Seal with Door
60
Door Lock Removal (Touchtronic/Novotronic/Navitronic)
61
Figure 020-13: Re-Installing the Door Seal
61
Figure 020-14: Door Lock Removal (Touchtronic/Novotronic/Navitronic)
61
Door Switch Replacement (Touchtronic/Novotronic/Navitronic)
62
Door Lock with Contact Switch Removal (Incognito)
62
Activating the Door Lock Emergency Release (Incognito)
62
Figure 020-15: Door Lock Emergency Release
62
Comfort Door Closing Aid (CTSH) Removal (Laperla II)
63
Front Panel
64
Service
65
Custom Door Panel (GDU) Removal
65
Door Tension Adjustment
65
Figure 030-1: Integrated Door Panel Screw Locations
65
Figure 030-2: Door Tension Adjustment
65
Door Outer Panel Removal
66
Figure 030-3: Outer Door Panel Removal
66
Lower Access Cover Plate Removal
67
Connecting Strip Removal
67
Figure 030-4: Lower Access Cover Plate Removal
67
Inner Cabinet
68
Function
69
Cabinet Construction
69
Drying System
69
Figure 040-1: Recirculation Turbothermic Drying
69
Fan
70
Fault Repair
71
Condensation Forms on Adjacent Cabinets
71
Figure 040-2: Condenser Pocket
71
Noises During Drying Cycle
72
Service
72
Door Seal Replacement
72
Figure 040-3: Seal Install Guide
72
Technical Information
73
Basket Guide Removal
73
Figure 040-4: Basket Guide
73
Figure 040-5: Clip with Bolt
73
Toekick Removal
74
Steam Condenser Removal
74
Figure 040-6: Toekick Removal
74
Fan Removal
75
Connection Box Removal
75
Figure 040-7: Fan Removal
75
Figure 040-8: Connection Box
76
Water Paths
77
Function
78
Water Circulation
78
Figure 050-1: Water Paths - Diagram
78
Waterproof System (WPS)
79
Waterproof System Flow Rate Restrictor
80
Water Diverter
80
Figure 050-2: Flow Rate Restrictor
80
Figure 050-3: Water Diverter
81
Figure 050-4: Water Diverter Without EGS
82
Water Diverter Without EGS
82
Figure 050-5: Water Diverter with EGS
83
Water Diverter with EGS
83
Figure 050-6: Reactivation
84
Reactivation
84
Water Softener Programming
85
Flow Meter B3/4, Water Intake Quantity
85
Electronically Controlled Water Hardness (EGS)
85
Sensor Softener
86
Intelligent Tab Function (Select Models Only)
86
MPEH Circulation Pump (no Slide Shutter or Frequency Converter)
87
Figure 050-7: MPEH Circulation Pump
87
MPEW Circulation Pump (with Slide Shutter, no Frequency Converter)
88
Figure 050-8: MPEW Circulation Pump
88
MPPW Circulation Pump (with Frequency Converter & Slide Shutter)
89
Figure 050-9: MPPW Circulation Pump
89
Figure 050-10: MPPW Circulation Pump Voltages
90
Table 050-1: MPPW Pump Pressure Versus Wash Program
90
Heater Elements
91
Heater Pressure Switch, B1/13
91
NTC Temperature Sensor R30
92
Figure 050-11: Heater Pressure Switch
92
Turbidity Sensor (ECO Sensor III, Autosensor), B3/10
93
Table 050-2: Temperature Sensor R30 Resistance Values
93
Figure 050-12: Turbidity Sensor Circuit
94
Figure 050-13: Turbidity Sensor Location
94
Spray Arms
95
Spray Arm Sensing, Middle and Bottom Spray Arms (Excella/Laperla)
95
Table 050-3: Spray Arm Speeds
95
Filter Combination with Microfine Filter
96
Figure 050-14: Middle and Bottom Spray Arm Sensors
96
Drain Pump
97
Figure 050-15: Filter Combination in Sump
97
Fault Repair
98
Jammed Circulation Pump
98
Drain Pump Switches on and off at Short Intervals
98
Intake/Drain LED Flashes and Lights up Alternately (Incognito)
98
Foreign Object in Drain System
99
Figure 050-16: Microfine Filter Trap
99
Poor Drying Results
100
Service
100
Replacing the Waterproof System Restrictor
100
Figure 050-17: Waterproof System
101
Figure 050-18: Removing the Waterproof System Restrictor
101
Waterproof System (WPS) Removal
102
Flow Meter (Circuit Board) Removal
102
Removing the Top Spray Arm
102
Figure 050-19: Replacing the Waterproof System Restrictor
102
Removing the Middle Spray Arm
103
Removing the Bottom Spray Arm
103
Removing the Feed Pipe to the Top Spray Arm with Turbidity Sensor
103
Removing the Feed Pipe to the Middle Spray Arm
103
Replacing the Spray Arm Sensor
103
Removing the Water Diverter with Resin Chamber
104
Figure 050-20: Spray Arm Sensor
104
G 1Xxx/G 2Xxx
106
Removing EGS Solenoid Y5
106
Removing Reactivation Valve Y38
106
Removing the Circulation Pump
106
Removing the Circulation Pump Housing Cap (with Ring Heater)
107
Figure 050-21: Screws and Clips Securing the Pump Housing Cap
107
Slide Shutter Removal (Excella/Laperla)
108
Drive Removal (Excella/Laperla)
108
Figure 050-22: Slide Shutter Assembly
108
Pump Impeller Removal
109
Pump Housing Removal
109
Figure 050-23: Drive Cam
109
Pump Capacitor Removal
110
Removing the Heater Pressure Switch
110
Speed Sensor Removal (MPEW Pumps Only)
110
Removing the Drain Pump
110
Removing the Sump
111
Figure 050-24: Removing the Drain Pump
111
Removing the NTC Temperature Sensor
112
Removing the Float
112
Removing the Float Switch
112
Dismantling the Filter Combination
113
Figure 050-25: Combination Filter
113
Filter Combination Assembly (New Microfine Filter and Handle)
114
Figure 050-26: Microfine Filter Installation
114
Technical Information
115
Filter Combination Assembly (with Locking Piece)
115
Figure 050-27: Filter Combination Lock/Unlock Positions
115
Figure 050-28: Combination Filter Locking Clip (Unlocked)
116
Figure 050-29: Combination Filter Locking Clip (Locked)
116
Salt Container (in Sump) Removal
117
Filling the Salt Container in the Sump
118
Figure 050-30: Filling the Salt Container in the Sump
118
Salt Container in Door (SIT) Removal
119
Figure 050-31: SIT Screws and Plug
119
Brine Valve (Y60) Removal
120
Filling the Salt Container in the Door
120
Figure 050-32: Opening the Salt Container
121
Figure 050-33: Opening the Funnel
121
Water Level Check
122
Figure 050-34: Filling the Salt Container in the Door
122
Figure 050-35: Water Level Reference
122
Electronic
123
Function
124
General Operation
124
Novotronic Controls
124
Touchtronic/Navitronic Controls
124
Figure 080-1: Touchtronic/Navitronic Main Menu
124
Figure 080-2: Selected Program Display
124
Incognito Controls
125
Component Test
125
Figure 080-3: Selected Options
125
Figure 080-4: Incognito Main Menu
125
Figure 080-5: Selected Program Display
125
Test Sequence and Background Information
126
Machine Response Following a Power Failure
128
Turbo Function (Select Models)
128
Dishes Can be Added" Function (Laperla II)
129
Sensordry Feature (Select Models)
129
Drying Plus Function (Laperla II)
130
Figure 080-6: Drying Phase (before Program End)
131
Figure 080-7: Drying Plus (after Program End)
131
Dealer Demo Mode (Excella/Laperla)
132
Electronics ID Summary
132
Table 080-1: Electronics ID Summary
133
Programming of Language and Time of Day at First Commissioning (Excella/Laperla)
134
Fault Repair
134
Main Switch Is On, no Message in Display
134
Rinse Aid Used up too Quickly (Models with Sensordry)
134
Program Can be Selected but Not Started
134
Program Interrupted, no Fault Indication
135
Diagnostic Support Cannot Establish a Connection
135
Settings Selected During Initial Commissioning Are Not Saved
136
Tea Residues in "Sensor Wash" Program (ID No. -876)
136
Fault Code Summary
137
Table 080-2: Fault Code Summary
137
Fault Indications
138
Fault Indication in Models with Software ID -769
138
Table 080-3: Model-Specific Fault Indications
138
Fault Code F01: Water/Heating NTC or Leads Short-Circuited
139
Fault Code F02: Water/Heating NTC or Leads Open-Circuited
139
Fault Code F11: Drainage Fault
140
Figure 080-8: Circuit Test Path for F11
140
Fault Code F12: Water Intake Fault at Start of Step
141
Fault Code F13: Water Intake Fault at End of Step
143
Fault Code F14: Water Intake Fault: Heater Pressure Switch
145
Fault Code F15: Water Intake Fault - Hot Water
147
Fault Code F18: Flow Meter Stationary State Monitor B3/4
147
Fault Code F19: Flow Meter B3/4 Stiff and Not Turning Freely
148
Figure 080-9: F19 Start Rinse Block Water Intake
148
Figure 080-10: F19 Test Routine
148
Fault Code F24: Heater Relay Contact
149
Figure 080-11: Circuit Test Path for F24
150
Fault Code F25: Target Temperature Fault
151
Fault Code F26: Boiling Protection
151
Fault Code F32: Door Lock Does Not Close
152
Fault Code F33: Door Lock Does Not Open
152
Fault Code F36: Door Lock Switch Defective
153
Fault Code F40: Electronic Fault
153
Fault Code F42: Line Frequency Registration Fault
153
Fault Code F47: Faulty Interface between Selection-Display Electronic (BAE) & Control-Power Electronic (SLT)
153
Fault Code F51: Heater Pressure Switch
154
Figure 080-12: Circuit Test Path for F51 (Initial State)
154
Figure 080-13: Circuit Test Path for F51 (Testing State)
154
Fault Code F52: Heater Pressure Switch Has Reset During Heating
155
Fault Code F53: Speed Sensor Fault
156
Fault Code F63: Slide Shutter Fault
157
Fault Code F67: Circulation Pump Speed too Low
157
Fault Code F68: Circulation Pump Operating after Shutoff
158
Fault Code F69: Circulation Pump Blocked
158
Fault Code F70: Float Switch Fault
159
Fault Code F78: Circulation Pump Fault
160
Fault Code F79: Circulation Pump Interaction Fault
161
Fault Code F84: Slide Shutter Positioning Fault
161
Fault Code F85: Slide Shutter Signal Change Fault
162
Fault Code F86: Salt Container Lid Contact Fault
162
Fault Code F87: Sensor Softener Fault
163
Fault Code F88: Turbidity Sensor Fault
163
Fault Code F91: Load Size Registration Inactive
164
Technical Information
138
Service
164
Customer Programming
164
Table 080-4: Customer Programming Summary
165
Service Programming
166
Inspira and Advanta - G 118X/G 2170/G 218X
166
Table 080-5: Service Programming Mode Summary, G 118X/G 2170/G 218X
168
Optima - G 1202
169
Table 080-6: Water Hardness Settings, G 118X/G 2170/G 218X
169
Table 080-7: Rinse Aid Quantities, G 118X/G 2170/G 218X
169
Table 080-8: Service Programming Mode, G 1202
172
Optima - G 1262
173
Table 080-9: Water Hardness Settings, G 1202
173
Table 080-10: Rinse Aid Settings, G 1202
173
Table 080-11: Service Programming Mode, G 1262
176
Optima - G 1470/G 2470
177
Table 080-12: Water Hardness Settings, G 1262
177
Table 080-13: Rinse Aid Settings, G 1262
177
Table 080-14: Service Programming Mode, G 1470/G 2470
180
Optima - G 1472/G 2472
181
Table 080-15: Water Hardness Settings, G 1470/G 2470
181
Advanta - G 2020
184
Table 080-16: Service Programming Mode, G 1472/G 2472
184
Table 080-17: Water Hardness Settings, G 1472/G 2472
184
Table 080-18: Service Programming Mode Summary, G 2020
186
Inspira and Diamante - G 2120/G 2140/G 2150
187
Table 080-19: Water Hardness Settings, G 2020
187
Table 080-20: Rinse Aid Quantities, G 2020
187
Table 080-21: Service Programming Mode Summary, G 2120/G 2140/G 2150
189
Table 080-22: Water Hardness Settings, G 2120/G 2140/G 2150
189
Inspira and Diamante - G 2142/G 2143
190
Table 080-23: Rinse Aid Quantities, G 2120/G 2140/G 2150
190
Table 080-24: Service Programming Mode Summary, G 2142/G 2143
192
Table 080-25: Water Hardness Settings, G 2142/G 2143
192
Optima - G 2420/G 243X
193
Table 080-26: Rinse Aid Quantities, G 2142/G 2143
193
Table 080-27: Service Programming Mode, G 2420/G 243X
196
Excella - G 2630/G 2670
197
Table 080-28: Water Hardness Settings, G 2420/G 243X
197
Excella - G 2732
200
Table 080-29: Service Programming Mode, G 2630/G 2670
200
Laperla - G 283X/G 2872
203
Table 080-30: Service Programming Mode, G 2732
203
Table 080-31: Service Programming Mode, G 283X/G 2872
206
Activating Dealer Demo Mode (Excella/Laperla)
207
Activating/Deactivating the Sensor Softener; Manually Setting Water Hardness (Excella/Laperla)
207
G 1Xxx/G 2Xxx
173
Service Mode
208
Inspira and Advanta - G 118X/G 2170/G 218X
208
Optima - G 1202
209
Table 080-32: Service Mode Summary, G 118X/G 2170/G 218X
209
Optima - G 1262
210
Table 080-33: Service Mode Summary, G 1202
210
Optima - G 1470/G 2470
211
Table 080-34: Service Mode Summary, G 1262
211
Optima - G 1472/G 2472
212
Table 080-35: Service Mode Summary, G 1470/G 2470
212
Advanta - G 2020
213
Table 080-36: Service Mode Summary, G 1472/G 2472
213
Inspira and Diamante - G 2120/G 214X/G 2150
214
Table 080-37: Service Mode Summary, G 2020
214
Optima - G 2420/G 243X
215
Table 080-38: Service Mode Summary, G 2120/G 214X/G 2150
215
Excella - G 2630/G 2670
216
Table 080-39: Service Mode Summary, G 2420/G 243X
216
Table 080-40: Service Mode Summary, G 2630/G 2670
217
Excella - G 2732
218
Table 080-41: Service Mode Summary, G 2732
218
Table 080-42: Service Mode Summary, G 283X/G 2872
219
Fascia Panel
220
Fault Repair
221
On/Off Button Jams
221
Display Steams up
221
Service
222
Fascia Panel Removal (Touchtronic/Novotronic/Navitronic)
222
Figure 100-1: Screws Securing the Fascia Panel (Touchtronic/Novotronic/Navitronic)
222
Fascia Panel Removal (Incognito)
223
Control Panel Removal (Touchtronic/Novotronic)
223
On/Off Switch Removal (Touchtronic/Novotronic)
223
Figure 100-2: Fascia Panel Removal (Incognito)
223
Electronic Removal (Incognito)
224
Figure 100-3: On/Off Switch Removal (Touchtronic/Novotronic)
224
Electronic Removal (Touchtronic/Novotronic)
225
Cutlery Tray
226
Fault Repair
227
Water Droplets on the Cutlery Tray
227
Technical Service Bulletins
228
Intermittent Buzzing/Vibration Noise from G 1000/2000 Dishwashers
228
G 2630 Electronic Replacement
228
Changing the Door Handle Style on a Dishwasher Delivered as 'SF' (Pre-Finished)
229
Re-Designed Cutlery Trays Are Now Available for G 2000 Series Dishwashers231
231
G 1000 and G 2000 Dishwashers Have an Updated Electronic for Even Quieter Operation of the Circulation Pump
231
Fascia Panel Replacement Instructions for the G 2830
231
Some F13 Faults in the G 2000 Dishwashers May be Caused by a Clogged Flow Restrictor
232
Winterizing Procedure for G 2Xxx Series Dishwashers
232
G 2000 Circulation Pumps Have a New Speed Sensor Configuration
234
G 2000 Dishwashers in Vacation Homes: F14, F69, or All Leds Blink
235
Circulation Pumps; MPEW Speed Sensors
235
G 2Xx2 Fault Code F79
235
Update; Replacing the Waterproof Hose in a Dishwasher
236
Technical Information
237
F11 Drainage Fault; Non-Return Valve
237
G 2143; G 2472 Lower Spray Arms
237
Miele Policy on Dishwasher Detergent Requirements
238
Dishwasher Detergents and Phosphates
239
Other manuals for Miele G 2 Series
Operating Instructions
76 pages
Manual
46 pages
4
Based on 1 rating
Ask a question
Give review
Questions and Answers:
Need help?
Do you have a question about the Miele G 2 Series and is the answer not in the manual?
Ask a question
Miele G 2 Series Specifications
General
Brand
Miele
Model
G 2 Series
Category
Dishwasher
Language
English
Related product manuals
Miele G 641
68 pages
Miele G 653
28 pages
Miele G 856
60 pages
Miele G 685
88 pages
Miele G 890
72 pages
Miele G 870
68 pages
Miele G 665
72 pages
Miele G 686
68 pages
Miele G 640
64 pages
Miele G 885
76 pages
Miele G 681
64 pages
Miele G 690
80 pages
To Next PageTo Next PageTo Previous PageTo Previous Page
Loading...
Need help?
General
