Technical data
87
Dishwasher model Standard XXL
Height 80.5 cm
(adjustable + 6.5 cm)
84.5 cm
(adjustable + 6.5 cm)
Height of building-in recess Min. 80.5 cm (+ 6.5
cm)
Min. 84.5 cm (+ 6.5
cm)
Width 59.8 cm 59.8 cm
Width of building-in recess 60 cm 60 cm
Depth 57 cm 57 cm
Weight max. 53 kg max. 59 kg
Voltage See data plate
Connected load See data plate
Fuse rating See data plate
Power consumption when
switched off
0.20 W 0.20 W
Power consumption when not
switched off
2.50 W 2.50 W
Test certificates awarded See data plate
Water pressure (flow rate) 30 - 1000 kPa
(0.3 - 10 bar)
30 - 1000 kPa
(0.3 - 10 bar)
Hot water connection Up to max. 60 °C Up to max. 60 °C
Delivery head Max. 1 m Max. 1 m
Drainage length Max. 4 m Max. 4 m
Mains cable Approx. 1.8 m Approx. 1.8 m
Capacity 13/14 place settings* 13/14 place settings*
* depending on model
