Technical Information
50
G 600/G 800
Figure 5-5: Cover Plate
Note:
When reinstalling the side panels, install the bottom lip of the panel into the edge of
the drip pan.
5.6 Connecting Strip Removal
1. Remove the cover plate. Refer to Section 5.5.
2. Remove the raised-head and countersunk screws (Figure 5-6, Item 1).
3. Remove all components from the connecting strip.
4. Remove the connecting strip.
Figure 5-6: Toekick Area with Connecting Strip
5.7 Basket Support Roller Replacement
1. Open the door.
2. Remove the top basket.
