Technical Information
80
G 600/G 800
6.6 Timing Charts and Wiring Diagrams (Model-Specific)
Refer to the timing chart and wiring diagram guide at the end of this section.
6.7 Fault Repair
6.7.1 Door Does Not Close Correctly
 Incorrectly installed stopper at end of top basket guide. Remove the stopper and
install it correctly; see Section 5.7.
 Door seal incorrectly installed and protrudes forwards. Remove the door seal and
install it correctly; see Section 5.2.
 Damaged door hinges. Inspect and replace hinges, as necessary; see Section
5.13.
 Power relay 1K1/6 not activated (Vi models only). Check the main switch (S2)
circuit.
6.7.2 Excess Foaming
 Too much (or improper type of) detergent and/or rinse aid is being used.
1. Use the correct type and amount of detergent.
2. Reduce the setting on the rinse aid dispenser.
3. If rinse aid spills while filling the dispenser, wipe it away.
 Detergent added to rinse aid dispenser. Remove the dispenser (see Section 5.8)
and thoroughly flush it out.
Note:
If the dispenser cannot be completely flushed out, replace the dispenser assembly
(see Section 5.8).
6.7.3 Detergent Not Released
 Basket incorrectly loaded.
Load the basket in accordance with the operating instructions.
 Middle spray arm is blocked.
Inspect the spray arm and check rotation.
6.7.4 Water Leaks from the Turbothermic Fan Grille
 Hose between fan and dispenser is blocked. Inspect hose and replace as
necessary (see Section 5.9).
 The PTC flap is not closing correctly. Inspect flap. Replace the turbothermic fan
as necessary (see Section 5.9).
6.7.5 Poor Drying Results
 Incorrect dispenser setting.
Adjust setting as necessary.
 Rinse aid dispenser flap not properly closed. The rinse aid container filled with
water during program operation.
1. Flush the dispenser; refill with new rinse aid.
2. Replace dispenser assembly as necessary; see Section 5.8.
