Before building the appliance in you will
need to decide on the door hinging. If
left hand door hinging is required follow
these instructions.
^
Open the appliance doors and
slightly loosen screws a on the
appliance using a Pozidrive
screwdriver.
^
Push the doors outwards and take
them off their hinges.
^
Take covers c off, and remove
screws d.
^
Remove screws a and refit them
loosely on the opposite side in the
2nd and 4th fixing holes from the
outside.
With the middle 4 fixing screws a,
you should first transfer to top two
screws, and then the bottom two. Do
not transfer all 4 screws at once.
^
Fit screws d into the inner fixing
holes on the opposite side.
^
Remove door fixing screws b, and
refit the hinges in their diagonally
opposite corners.
^ Refit the appliance doors onto
pre-fitted screws a, then tighten the
screws.
^ Cover the holes which are now open
using covers c and stoppers e.
Changing the door hinging
35
