Prepare the worktop cut-out as
shown in the diagram.
Remember to maintain a minimum
safety distance of 50 mm between
the hob and the back wall and
150 mm between it and a side wall or
tall unit to the right or left of the hob.
(See "Warning and Safety
instructions").
^
Seal the cut surfaces with a suitable
heat-resistant sealant to avoid
swelling caused by moisture.
If during installation, the corners of
the frame are not flush with the
worktop surface, the corner radius,
Max R4 can be carefully scribed to
suit.
Appliance dimensions and worktop cut-out
12
