Technical Information
34
MasterChef Collection Cooktops
5.1 Removing Cooktop for Service
Should the internal components of the cooktop require service, the
Cooktop must be removed.
Removal Procedure
Refer to Figure 5-1.
1. Shut off the electrical supply to the appliance (i.e. shut off the
circuit breaker). Turn off the gas supply (if applicable)
2. Disconnect the electrical supply. Disconnect the gas (if
applicable).
3. Access the underside of the appliance.
4. Press inward on the retaining clips (1) while pushing the
appliance upward (2)
Note:
During re-installation all gas connections must be leaked tested
before reconnecting the electric supply.
Figure 5-1: Removing the Cooktop for Service
