Removing the plinth panel
The electrical connection point is
located behind the front plinth panel in
the middle.
,
Disconnect the machine from the
mains electricity supply.
^
Unscrew the plinth panel by
loosening the 2 screws on the left
and right hand sides.
^
Secure the plinth panel back in
position once connection has been
successfully completed.
Please refer to the installation
diagram supplied with the machine.
Equipotential bonding connection
There is a screw connection point
marked with the earth symbol (8)atthe
back of the machine, to which
additional equipotential bonding can be
connected.
Electrical connection
64
