Miele SMUL0 - Attaching the Mounting Plate; Attaching the Charging Cable to the Wall Bracket

20
Attaching the mounting plate
2plugs and 2T20 TORX screws are
supplied for attaching the mounting
plate to the wall.
You will also need a battery-operated
screwdriver or a drill (with a drilling dia-
meter of 6mm).
Depending on how your vacuum
cleaner is configured, select a distance
of 45cm or 98cm between the bottom
edge of the mounting plate and the
floor.
Be careful not to damage any cables
laid in the wall.
 Attach the mounting plate to the wall.
Attaching the charging cable to the
wall bracket
A cable compartment is located on the
underside of the wall bracket.
 Press both release catches on the un-
derside of the wall bracket and re-
move the cable compartment cover.
 Insert the supplied charging cable
into the opening from above.
 Lay the charging cable in its guide.
