The dryer is fitted with a non-return
valve as standard to prevent water from
flowing back into the machine.
Close the water inlet port to the con-
densed water container with the bot-
tom part of the rubber plug.
The plug must face towards the inte-
rior of the machine so that the con-
densed water container can be
pushed in easily.
Connection to wash basin drain out-
let (where appropriate)
Push the hose clip (1) and the
knurled nut connector from the sink
drain outlet (2) over the drain hose.
Push the adapter sleeve (3) into the
hose.
Screw the drain hose to the drain out-
let with the knurled nut connector.
Tighten the hose clip up close to the
nut.
Installation
37
