Exhaust connection
Using the connector supplied, an
exhaust hose (4" [100 mm]
diameter) can be installed.
Necessary materials:
–
a wall or window duct
(available from Miele)
–
an exhaust hose/pipe made of
approved non-flammable material
^
Install the exhaust hose/pipe, 2, with
the connector, 1, to the dryer.
Window connection
1 Window duct ( (installed in a
"plexiglass" pane)
2 Connector for the flexible metal
exhaust hose
Wall connection with rigid pipe
1 Wall pipe (Installation sheet supplied
with the Miele wall pipe)
2 Connector
3 Rigid pipe
Installation
31
