Miele TWB 140 WP User Manual

Installation
*INSTALLATION*
58
Installation
Levelling the dryer
 The appliance must not be
installed behind a lockable door, a
sliding door or a door with a hinge on
the opposite side to that of the
tumble dryer, in such a way that a full
opening of the tumble dryer door is
restricted.
Make sure the dryer door can be
opened without hindrance after
installation.
The appliance must stand perfectly
level to ensure safe and proper
operation.
The screw feet can be adjusted to
compensate for any unevenness in the
floor.
 Risk of fire and explosion due to
damage to the tumble dryer.
The refrigerant is flammable and
explosive.
Do not make any alterations to the
tumble dryer. Take measures to
protect the tumble dryer against
damage.
If the tumble dryer is damaged, proceed
as follows:
– Avoid naked flames or anything
which creates a spark.
– Disconnect the dryer from the
electricity supply.
– Air the room where the tumble dryer
is located.
– Contact Miele Customer Service.

Miele TWB 140 WP Specifications

General

Drum type	Honeycomb
Color name	Lotus white
Door hinge	Left
Door style	Opaque door
Cord length	2 m
Control type	Rotary, Touch
Loading type	Front-load
Drying system	Heat pump
Product color	White
Reversible doors	-
Appliance placement	Freestanding
Inverter technology	Yes
Cycle time	155 min
Noise level	66 dB
Drying class	A
Drum capacity	7 kg
Refrigerating medium	R290
Refrigerating medium weight	110 g
Current	13 A
Heat source	Electric
Connected load	1100 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy consumption	1.7 kWh
Energy efficiency scale	A+++ to D
Power consumption (off)	0.3 W
Annual energy consumption	208 kWh
Delay start (max)	24 h

Weight and Dimensions

Depth	643 mm
Width	596 mm
Height	850 mm
Weight	58000 g
Depth with door open	1077 mm
