Miele TWB 140 WP User Manual

Installation
*INSTALLATION*
62
Arranging the drain hose
 Damage to the drain hose
through incorrect handling.
The drain hose can suffer damage
and leak.
Do not pull on the drain hose and do
not stretch it or allow it to become
kinked.
There will be a small amount of residual
water left in the drain hose. Have a
container ready to collect this.
 Pull the drain hose off its connection
(light arrow).
 Pull the hose out of the holders (dark
arrows) and unwind it.
 Allow any residual water to run into a
container.
Examples
Drainage into a laundry tub or floor gully
Use the hose holder to secure the drain
hose.
 Risk of water damage.
Should the end of the hose come
loose, overflowing water can cause
damage.
Secure the drain hose carefully (e.g.,
by tying it) to make sure it cannot
slip.
The non-return valve can be fitted in the
end of the hose.

Miele TWB 140 WP Specifications

General

Drum type	Honeycomb
Color name	Lotus white
Door hinge	Left
Door style	Opaque door
Cord length	2 m
Control type	Rotary, Touch
Loading type	Front-load
Drying system	Heat pump
Product color	White
Reversible doors	-
Appliance placement	Freestanding
Inverter technology	Yes
Cycle time	155 min
Noise level	66 dB
Drying class	A
Drum capacity	7 kg
Refrigerating medium	R290
Refrigerating medium weight	110 g
Current	13 A
Heat source	Electric
Connected load	1100 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy consumption	1.7 kWh
Energy efficiency scale	A+++ to D
Power consumption (off)	0.3 W
Annual energy consumption	208 kWh
Delay start (max)	24 h

Weight and Dimensions

Depth	643 mm
Width	596 mm
Height	850 mm
Weight	58000 g
Depth with door open	1077 mm
