Miele TWB 140 WP User Manual

Installation
*INSTALLATION*
67
5. Change the door hinge on the door
The door hinge is secured to the door
with 2 angled rods. These rods need
to be removed with a screwdriver or
pointed pliers.
 Insert the end of the screwdriver
blade under the rod  and rotate it
so it is in an upright position. Do the
same to the other rod.
 Use the screwdriver or pointed pliers
to guide first one then the other
rod to the middle until each can be
removed.
Useful tip: In some circumstances, the
rods can be difficult to dislodge.
Moving the screwdriver with a levering
action while pulling at the same time
may help to work the rods free.
 Remove the door hinge and rotate it
180°.
 Refit the door hinge on the opposite
side of the door.
 Secure the door hinge with the two
rods .
 Position the tip of the screwdriver
under the end of the rod and then
push it into its resting position.

Miele TWB 140 WP Specifications

General

Drum type	Honeycomb
Color name	Lotus white
Door hinge	Left
Door style	Opaque door
Cord length	2 m
Control type	Rotary, Touch
Loading type	Front-load
Drying system	Heat pump
Product color	White
Reversible doors	-
Appliance placement	Freestanding
Inverter technology	Yes
Cycle time	155 min
Noise level	66 dB
Drying class	A
Drum capacity	7 kg
Refrigerating medium	R290
Refrigerating medium weight	110 g
Current	13 A
Heat source	Electric
Connected load	1100 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy consumption	1.7 kWh
Energy efficiency scale	A+++ to D
Power consumption (off)	0.3 W
Annual energy consumption	208 kWh
Delay start (max)	24 h

Weight and Dimensions

Depth	643 mm
Width	596 mm
Height	850 mm
Weight	58000 g
Depth with door open	1077 mm
