Load Consumption data
Energy Water Duration
in kWh in litres Normal Intensive
COTTONS
95°C 5.0 kg 1.70 45 1 h 32 min 1 h 47 min
60°C
1)
5.0 kg 0.95 45 – 1 h 56 min
1)
60°C 5.0 kg 0.95 45 1 h 26 min 1 h 56 min
40°C
1)
5.0 kg 0.50 45 – 1 h 56 min
1)
40°C 5.0 kg 0.50 45 1 h 26 min 1 h 56 min
MINIMUM IRON
40°C
1)
2.5 kg 0.45 49
–
1 h 16 min
1)
40°C 2.5 kg 0.45 49 1 h 01 min 1 h 16 min
DELICATES
30°C 1.0 kg 0.35 65 49 min 59 min
Silks /
30°C 1.0 kg 0.24 39 37 min –
WOOLLENS /
30°C 2.0 kg 0.23 35 40 min –
1)
EN 60456 test programme
Note for test institutes:
For testing in accordance with EN 60456 you must use the
Intensive
option.
Consumption data can vary from the nominal values given depending on water
pressure, water hardness, water inlet temperature, room temperature, type and
volume of load, fluctuations in the electricity supply and any additional options
selected.
Consumption data
55
