Miele WSG 663 Series User Manual

Technical data
86
Height 850 mm
Width 596 mm
Depth 643 mm
Depth with door open 1077 mm
Height for building under 850 mm
Width for building under 600 mm
Weight Approx. 96 kg
Capacity 8 kg dry laundry
Voltage See data plate
Connected load See data plate
Fuse rating See data plate
Consumption data See “Consumption data”
Minimum water flow pressure 100kPa (1bar)
Maximum water flow pressure 1000kPa (10bar)
Intake hose length 1.60m
Drain hose length 1.50m
Mains connection cable length 2m
Maximum drain pump head height 1m
Maximum drain hose length 5m
LEDs Class 1
Test certificates awarded See data plate
Frequency band 2.4000GHz – 2.4835GHz
Maximum transmitting power < 100mW

Miele WSG 663 Series Specifications

General

Brand	Miele
Model	WSG 663 Series
Category	Washer
Language	English
