5
PACKAGE CONTENTS
(1) Battery Enclosure Kit and Cover
(4) Battery Enclosure Kit Cover Screws
(4) Mounting Screws
(1) 12V 7 Ah Battery
(FM150 or RB500)
NOTE: An additional FM150 or RB500 is
recommended for solar installations (purchased
separately).
(1) Strain Relief Fitting
(2) IDC Self Stripping Connectors
NOTE: ONLY the use of the supplied IDC
Connector will not void your Mighty Mule
product warranty.
(1) Battery Harness A
(1) Battery Harness B
To Battery Harness B
To Control
Board
To Battery
To Battery
To Battery
Harness A
Black –
Red +
Black –
Black –
Red +
Red +
To Next Page
