MikroTik Chateau LTE18 ax User Manual

Powering
 A number of DC inputs 1.
 DC jack input Voltage 12-28 V.
 Power adapter nominal voltage 24 V.
 Power adapter nominal current 1.2 A.
 Max power consumption without attachments 16 W.
 Max power consumption 19 W.
Configuration
We recommend checking for updates frequently to receive the latest updates for your RouterOS
software to ensure the best performance and stability.
RouterOS includes many configuration options in addition to what is described in this document. We
suggest starting here to get yourself accustomed to the possibilities: https://mt.lv/help. In case an IP
connection is not available, the Winbox tool (https://mt.lv/winbox) can be used to connect to the MAC
address of the device from the LAN side (all access is blocked from the Internet port by default).
For recovery purposes, it is possible to boot the device for reinstallation, see the section Buttons and
Jumpers.
Mode button
The mode button is located on the back of the unit, on the right side.
The Default configuration for the Mode button is dark mode - to turn off all LEDs. The button can be
configured in RouterOS to run any user-specified scripts.
Sync button
The sync button is located on the top of the unit. The WPS Sync button, if configured on the wireless
interface, can be used to connect new clients.
 Press and hold the WPS button for 1 – 5 seconds to enable WPS for wireless interfaces.

MikroTik Chateau LTE18 ax Specifications

General

DSL WAN	-
Ethernet WAN	Yes
WAN connection type	RJ-45
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN data transfer rate (max)	1200 Mbit/s
WLAN data transfer rate (first band)	574 Mbit/s
Antennas quantity	2
Antenna gain level (max)	6 dBi
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	2500 Mbit/s
Ethernet LAN interface type	Ethernet
4G standard	LTE-TDD & LTE-FDD
SIM card type	MicroSIM
4G bands supported	700, 800, 850, 900, 1800, 2100, 2300, 2500, 2600 MHz
GSM bands supported	850, 900, 1800, 2100 MHz
Mobile network generation	4G
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	4
Product type	Tabletop router
Product color	White
Certification	CE, EAC
Internal memory	128 MB
Processor frequency	864 MHz
RAM capacity (Wi-Fi point)	1000 MB
Output voltage	12 - 28 V
Power source type	DC
Power consumption (typical)	16 W
Operating temperature (T-T)	-40 - 65 °C
Sustainability certificates	RoHS
Cables included	UTP

Weight and Dimensions

Depth	156 mm
Width	240 mm
Height	44 mm
