Page #2 background image
Powering
Number of DC inputs 2 (PoE-in, DC jack)
PoE-in input Voltage 18-28 V
DC jack input Voltage 12-28 V
PoE-out Passive PoE Ether1, max out per port output (input < 30 V): 600mA
Max total out 0.6 A
Total output power 16.8 W
Power adapter nominal voltage 24 V
Power adapter nominal current 1.2 A
Max power consumption (without attachments) 12 W
Max power consumption 27 W
Setup
1. Make sure your Internet service provider is allowing hardware change and will issue an automatic IP
address;
2. Connect the device to the power source;
3. Open network connections on your computer and search for "MikroTik-..." wireless network - connect
to it;
4. The configuration can be done through the wireless network using a web browser or mobile app.
Alternatively, you can use a WinBox configuration tool https://mt.lv/winbox;
5. Open https://192.168.88.1 in your web browser to start configuration, user name: admin and there is no
password by default (or, for some models, check user and wireless passwords on the sticker);
6. Click the (Check for updates) button and update your RouterOS software to the latest version;
7. Choose your country, to apply country regulation settings;
8. Set up your wireless network password;
9. Set up your router password;
10.The following RouterOS "npk" packages are required for the core functionality of the product:
wifiwave2, system.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the MikroTik hAP ax2 and is the answer not in the manual?

MikroTik hAP ax2 Specifications

General IconGeneral
Product NameMikroTik hAP ax2
CategoryWireless Router
CPUIPQ-6010
CPU core count4
Size of RAM1 GB
Storage size128 MB
Storage typeNAND
Wireless 2.4 GHz Max data rate574 Mbps
Wireless 5 GHz Max data rate1200 Mbps
Wireless Standards802.11a/b/g/n/ac/ax
Wireless SpeedAX1800
Antenna gain dBi for 5 GHz5.5 dBi
Operating systemRouterOS
Wireless generationWi-Fi 6
PoE in802.3af/at
PoE outNo
DC input voltage12-28 V
Max power consumption without attachments12 W
Ethernet Ports5
Frequency Band2.4 GHz / 5 GHz
Power Supply24V
