MikroTik netPower 16P User Manual

1.
2.
3.
4.
5.
6.
7.
8.
9.
1.
2.
3.
DC power connector 48 – 57 V.
DC power connector 18 – 30 V.
LED indicating a power state of the device.
Reset button.
Gigabit Ethernet, 8 - ports, delivering PoE out.
Gigabit Ethernet, 8 - ports, delivering PoE out.
Two - 10G SFP+ ports.
LED Indicating the activity of SFP port.
LED Indicating the speed of SFP port.
Configuration
The device can be discovered using Winbox utility, by clicking on the Neighbors list. The default management address is 192.168.88.1. To reach both
devices needs to be in the same IP network. Configured as a bridge, ARP, and fast forward enabled. RSTP protocol activated.
RouterOS includes many configuration options in addition to what is described in this document. We suggest starting here to get yourself accustomed to
the possibilities: .https://mt.lv/help
For recovery purposes, it is possible to boot the device for reinstallation, see section .Buttons and Jumpers
Powering
The device accepts power in the two ways following ways:
Direct-input power jack 1, (5.5 mm outside and 2 mm inside, female, pin positive plug) accepts 18-30 V DC.
Direct-input power jack 2, 48-57 V DC .
Use included DC plug to connect with your power source:
DC plug 2.1x5.5x12 mm to Screw Terminal 2pin.
Connect your power source cables to the two pins and secure them in place by tightening screws.
Connect DC plug to the device.
The power consumption under maximum load can reach 21 W, with attachments 325 W.
Power output

MikroTik netPower 16P Specifications

General

Switch type	-
Switch layer	L2/L3
Flash memory	16 MB
Internal memory	256 MB
Processor model	98DX226S
Built-in processor	Yes
Processor frequency	800 MHz
Operating temperature (T-T)	-40 - 70 °C
Power connector	DC-in jack
SFP+ module slots quantity	2
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	16
DC input voltage	18 - 57 V
Power consumption (max)	316 W
10G support	No
Networking standards	IEEE 802.3af, IEEE 802.3at
Certification	CE/RED, EAC, RoHS
Product color	White
Forwarding rate	53.6 Mpps
MAC address table	- entries

Weight and Dimensions

Depth	78 mm
Width	212 mm
Height	303 mm
