RouterBOARD 411 Series User's Manual
Specifications
RouterBOARD 411
CPU MIPS24k based, Atheros AR7130 300MHz CPU
Memory 32MB SDRAM onboard memory
Boot loader RouterBOOT
Data storage 64MB onboard NAND memory chip
Ethernet One 10/100 Mbit/s Fast Ethernet ports supporting Auto-MDI/X
MiniPCI slot One MiniPCI Type IIIA/IIIB slot
Serial port One DB9 RS232C asynchronous serial port
LEDs Power and User LED, 5 status LEDs
Speaker Mini PC-Speaker
Power options
Power over Ethernet: 12..28V DC (except power over datalines)
Power jack: 9..28V DC
Dimensions 105mm x 105mm
Weight 115 g (4.06 oz)
Temperature Operational: -20°C to +65°C (-4°F to 149°F)
Humidity Operational: up to 70% relative humidity (non-condensing)
Power consumption 3-4W without extension cards, maximum – 14W
Hardware Guide
Memory and Storage Devices
Onboard Memory
The board is equipped with 32 MB DDR onboard memory.
Onboard NAND Storage Device
The boards are equipped with one 64MB NAND nonvolatile memory chip.
Extension Slots
MiniPCI Slots
The board has one MiniPCI Type IIIA slot with 3.3V only power signaling. It also accepts MiniPCI Type IIIB
standard cards. The board has been tested to operate with high power cards if ambient temperature and
adequate cooling is ensured.
NOTE: that RB400 series currently does not support Senao 8602 cards, Atheros AR5211 or older chipset and
Prism chipset based cards. Wireless compression is not supported on RB400 series devices.
Supplied power for the extension cards (excluding CPU and onboard Ethernet ports):
+3.3V: 3.3A max
Input/Output Ports
LAN1 Port with PoE
This Fast Ethernet port is recognized as the first LAN interface. It is compatible with passive (non-standard)
Power over Ethernet. The board accepts voltage input from 12 to 28 V DC. It is suggested to use higher
voltages for power over long cables because of better efficiency (less power is lost in the cable itself and
power supply is more efficient).
4
