RouterBOARD 411 Series User's Manual
Connector Index
J401 MiniPCI Type type IIIA/B connector
J301 RS232C male DB9 serial port
1 DCD (Data Carrier Detect)
2 RxD (Receive Data)
3 TxD (Transmit Data)
5 GND
6 DSR (Data Set Ready)
8 CTS (Clear to Send)
J602 RJ45 Fast Ethernet 100Base-TX port LAN1 with passive PoE extension
1 Data TX+
2 Data TX-
3 Data RX+
4
5
6
7
8
PoE power +
PoE power +
Data RX-
PoE power -
PoE power -
J801 Power jack (9..28 V DC, positive contact is the central pin)
Button Index
S301 Software reset button
Ethernet Cables
RJ45
Pin
Color Function RJ45 pin for Straight
cable
(MDI, EIA/TIA568A)
RJ45 pin for Crossover
cable
(MDI-X, EIA/TIA568B)
1 Green TX+ Data 1 3
2 Green/White TX- Data 2 6
3 Orange RX+ Data 3 1
4 Blue - 4 4
5 Blue/White - 5 5
6 Orange/White RX- Data 6 2
7 Brown - 7 7
8 Brown/White - 8 8
9
