Miku SUPER - DESCRIPTION OF COMPONENTS & PARTS; Diagram of Components; Diagram of Dashboard

04 DESCRIPTION OF COMPONENTS & PARTS
06
Diagram of Components
07
Diagram of Dashboard
Battery case
Head light
Mirror
Storage
Seat
Passenger
foot rest
Tail light
Front
suspension
Disc brake system
Side stand
Disc brake system
Motor
Rear swingarm
Instrument
Rear brake lever
Left switch
Tuning light
Right switch
Throttle grip
Front brake lever
Brake oil tank
D
B1
%
%
B2
000000ODO:
km
km/h
100
120
80
60
40
20
0
POWER CHARGE
mph
miles
Battery charging hint
indicator
Position lights indicator
Malfunction indicator
Driving beam indicator
Handle failure indicator
Brake failure indicator
Right direction indicator
Left direction indicator
Controller failure indicator
Battery capacity display
%
%
Speed display
km/h
mph
READY
Ready indicator
Mileage display
km
mile
ODO:000000
Bluetooth indicator
Central control signal
indicator
Tyre failure indicator
D
Drive mode
DESIGNED BY MIKU TEAM DESIGNED BY MIKU TEAM
Note: The following is MIKU Super smart version instrument.
