Milesight MS-C2181-P - Page 10

User Manual
www.milesight.com
4
Figure 1-4
3. Dome Camera
Video Output
Power Connector (DC 12V)
Audio Output
Audio Input
RS-485 PTZ control
Alarm Input/ Output
Ethernet Port
Figure 1-5
*Note:
1) The network camera provides a general I/O terminal block which is used to connect external
