Date Format The format of date
Figure 4-7
Primary Stream Settings
Parameters Function Introduction
Video Codec H.264/MPEG-4/MJPEG available (Main stream only support H.264)
Frame Size
Options include 5M(2560 × 1920), 3M(2048 × 1536), 1080P(1920×
1080), 2M(1600 ×1200), 1.3M(1280×960), 720P(1280×720),D1 (704×576)
Maximum Frame Rate Maximum refresh frame rate of per second
Bit Rate Transmitting bits of data per second
Bit Rate Control
CBR : Constant Bitrate. The rate at which a codec's output data should be
consumed is constant
VBR : Variable Bitrate. VBR files vary the amount of output date per time
segment
Profile The option of codec, select Base/Main/High according to your needs
I-frame Interval Set the I-frame interval to 1~30
Note:
The options of Frame Size are variable according to the model selected.
