Millarco 62.090 - Starting Checklist

Pruning Saw Attachment Assembly
1. Remove the chain cover from the pruning saw attachment head
2. Fit the bar (5) to the pruning saw head.
3. Fit the saw chain (6) to the bar.
4.Adjustthechaintensionasnecessary.
5. Replace the chain cover.
Warning – Please ensure the pruning attachment bar/ chain lubrication tank is
lledwithbarlubeoilbeforeoperating.Oilcapacity-150ml.
Hedge Trimming Attachment Assembly
1. The hedge trimming attachment comes pre-assembled and is ready for use.
 Allthatisrequiredforoperationisthecuttingheadtobesettothedesired
angle and set in place. Then remove the safety covers from the cutting
blades.
Assembling Attachments to Main Engine Shaft
1.Loosentheshaftcouplinghandleandreleasethelockingcatch.
2. Slide the attachment shaft into the attachment shaft, ensuring the main shaft
locating pin lines up with the hole in the attachment shaft. Check the drive
spline on the motor drive shaft has located correctly into the attachment drive
shaft. This may require the attachment head or the engine to be rotated
slightly.
3. Replace the locking catch into place and tighten the shaft coupling handle.
IMPORTANT:Donotstarttheunituntilithasbeencompletelyassembled.Before
switching on the unit, always checking the oil.
Check Machine before Use
Check the safety condition of the device:
1. Check the machine for leaks.
2. Check the machine for visual defects.
3.Checkthatallpartsofthemachinehavebeensecurelytted.
4. Check that all safety devices are in proper condition.
WARNING: Do not operate this machine if you have found
any faults. To operate this machine with faults could result in
serious injury. Make sure to replace faulty parts before
using the machine again.
Adjusting the Harness
1.Adjusttheharnesssothequick-releaselatchisatyour
right hip, as shown.
Starting checklist
