Millenium MPS-500 USB Assembly Instructions

Bass drum and hi-hat
1. Position the bass drum pad centred under the rack. Position the bass drum pedal centred in front of the pad.
2. Place the hi-hat pedal to the left of the bass drum pedal.
Set-up and cabling
Set up the rack, the pads and the cymbals according to your needs. As a final step, all triggers need to be wired to the drum
module. Note the labelling on the drum module and the colour markings of each cable.
Assembly
e-drum set
10
