8 Connector and pin assignments
This chapter will help you select the right cables and plugs to connect your valuable equip‐
ment in such a way that a perfect sound experience is ensured.
Please note these advices, because especially in ‘Sound & Light’ caution is indicated: Even if a
plug fits into the socket, an incorrect connection may result in a destroyed power amp, a short
circuit or ‘just’ in poor transmission quality!
1 Signal
2 Ground, shielding
Introduction
1/4" TS phone plug (mono,
unbalanced)
Connector and pin assignments
e-drum module
50
