OM-244 997 Page 21
B. Table Tops
1 Table Tops
Locate table tops and place flat on
the floor.
. Tops for 60SX model shown,
solid tops use the same tapped
hole layout.
. X-pattern top can be on either
side. Check the following
instructions to be sure how
tops will be positioned after
assembly.
Use a mallet to tap tops together so
they touch at the center.
1
Four holes must be
together in center of tops.
Tools Needed:
C. Support Rails
1 Tapped Holes For Front/Rear
Rails
2 Front/Rear Rails
Place four front/rear rails on table
tops as shown, but do not fasten
rails to tops yet.
2
2
1
1
1
1
1
1
11
Bottom View
