Miller ArcStation - Installing Optional Vise Kit

OM-244 997 Page 32
5-4. Installing Optional Vise Kit
1 Optional Vise Mount
Install and secure vise to the vise
mount using the supplied
hardware.
Remove tube cap from end
subframe tube.
Insert vise mount into end subframe
tube and secure with supplied bolt
FF.
Tools Needed:
9/16 in.
1
hex bit 5/16 in.
FF
9/16 in.
